HSM V-Press 504 Eco

The entry-level HSM V-Press 504 Eco is an economical solution for disposing of your packaging waste. This compact and sturdy baling press is designed to fit into small spaces while delivering reliable performance. Equipped with a modern microprocessor controller featuring a membrane keypad and text display, the V-Press 504 is easy to operate. The HSM V-Press 504 features selectable programs for pressing cardboard or plastic, offering versatility as both a plastic and cardboard baler. Additionally, the bale removal and transport are simplified with a discharge trolley, and an optional mechanical bale ejector is available for added convenience.

Applications:
  • Baling of cartons, plastics, cardboard, etc.
  • Small supermarket baler
Download library
HSM V Press 504 Trash Baler

Product Info

The HSM V-Press 504 is engineered for efficiency and ease of use. Its compact design ensures it occupies a minimal footprint, making it suitable for small spaces. The microprocessor controller with a membrane keypad and text display provides intuitive operation, while selectable programs for cardboard and plastic film enhance versatility. Bale removal and transport are made easy with the included discharge trolley, and the optional mechanical bale ejector adds further convenience. The HSM V-Press 504 features the Torsion Control System (TCS) for monitoring press ram movement and includes an automatic return stroke for smooth operation. The eco configuration offers a double door with a bell-crank lever, ensuring robust and efficient baling.

Technical Specifications

Pressing Power 40 kN
Specific Pressing Power 11.2 N/cm²
Driving Power 1.1 kW
Voltage / Frequency 230 V / 50 Hz
Cycle Time When Idling 27 s
Machine Dimensions (Width x Depth x Height) 1020 mm x 812 mm x 1922 mm
Loading Aperture Dimensions (Width x Height) 700 mm x 470 mm
Bale Dimensions (Length x Width x Height) 700 mm x 500 mm x 600 mm
Bale Weight 60 kg approx.
Loading Height 661 mm
Machine Weight 290 kg
Method of Strapping Vertical
Number of Strappings 2
Type of Consumables Strapping tape
Disclaimer: The technical specifications outlined herein are subject to change based on ongoing product enhancements and specific customer requirements. For the most accurate and up-to-date specifications, please get in touch with us.
Your personal Consultant

Get Expert Advice To Buy the Right Product

How to buy get a quote chat with us

Accessories and Consumables

Strapping Tape WG30

Product FAQs

What are the dimensions of the HSM V-Press 504?

The machine dimensions are 1020 mm (width) x 812 mm (depth) x 1922 mm (height).

What materials can the HSM V-Press 504 press?

The HSM V-Press 504 Eco can process cardboard and plastic film/foil.

Is the HSM V-Press 504 easy to operate?

Yes, the plastic film and cardboard baler is easy to operate, featuring a modern microprocessor controller with a convenient membrane keypad and text display for intuitive use.

Does the V-Press 504 come with a discharge trolley?

Yes, the V-Press 504 comes with a discharge trolley for easy bale removal and transport. An optional mechanical bale ejector is also available.

What type of strapping is used for the bales in the V-Press 504?

The HSM V-Press 504 uses continuous polyester tape for manual bale strapping.

What safety features does the HSM V-Press 504 have?

The HSM V-Press 504 includes a hand-wheel door lock for quick and safe door opening, door sensors that automatically start the pressing process when the door is closed, and a Torsion Control System (TCS) that monitors press ram movement for safe and reliable operation.
